BRONZE FILTER CONE 32X41X46 150MICRON

Premium Quality Sintered Bronze Filter

DALON CONE FILTER

Product Overview

Product Specifications

Manufacturer DALON
Material POROUS BRONZE
Type CONE FILTER
Reference Drawing
Product Code SBF025025M150
Pore Pitch 150MICRON
HS Code 84219990
RoHS Compliant
REACH Compliant

Technical Drawings & Dimensions

Sintered Bronze Air filter Technical Drawing

Product Dimensions

I.D.(d) 32
I.D. (d1)
O.D. (D) 41
O.D. (D1)
Length (L) 46
Flange Dia. (fd)
Flange Thickness (fl)
General Tolerance ±0.3mm
Weight(ref)/Gram 131.00
Minimum Order Qty 0
All dimensions in millimeters (mm) unless otherwise specified.

Product Description

Sintered Bronze Air Filter - Cone Design | 32x41x46mm 150 Micron

BRONZE FILTER CONE 32X41X46  150MICRON Additional image 1

The BRONZE FILTER CONE 32×41×46 150MICRON is a robust, high-capacity sintered bronze air filter designed for air handling and pneumatic systems requiring efficient, low-restriction filtration. With a 150-micron pore size, this conical filter is ideal for pre-filtration, exhaust filtration, or particle separation in high-flow environments.

Its sintered metal body ensures exceptional durability, temperature resistance, and mechanical stability, allowing it to perform consistently under vibration, backpressure, and frequent cycling—common in air compressors, blowers, and industrial ventilation systems.


Key Specifications

  • Top Diameter: 32 mm

  • Base Diameter: 41 mm

  • Height: 46 mm

  • Material: Sintered Bronze

  • Filtration Rating: 150 micron

  • Operating Pressure: Up to 10 bar

  • Temperature Range: -40°C to +200°C

  • Cleaning Method: Backflushing, ultrasonic, or solvent rinse


Key Features

  • 150 Micron Coarse Filtration
    Captures dust, rust, and coarse particles while allowing strong air throughput—ideal for primary or exhaust filtration.

  • Conical Shape Design
    Supports high flow with low resistance and fits seamlessly into compressed air lines, housings, or blower ports.

  • Sintered Bronze Durability
    Metallic structure resists deformation, thermal stress, and corrosion over long service cycles.

  • Reusable & Cost-Effective
    Can be cleaned and reused multiple times, reducing operational cost over disposable alternatives.

  • Broad Industrial Compatibility
    Applicable in compressors, air intake systems, dust blowers, vacuum pumps, and more.


Typical Applications

  • Air Compressors & Pumps – Protects internal components by trapping large airborne contaminants.

  • Pneumatic Valves & Cylinders – Ensures clean air for accurate and reliable motion.

  • Industrial Blowers & HVAC Systems – Maintains ventilation hygiene and equipment performance.

  • Vacuum & Exhaust Systems – Functions as a primary barrier for dust and coarse debris.

  • Machinery Intakes – Suitable as a rugged intake filter in harsh industrial environments.


Why Choose DALON?

DALON is a trusted global supplier of sintered filtration components, with over 20 years of experience delivering precision-engineered bronze and stainless steel filters. Every product is made under ISO-certified manufacturing and quality control systems, offering:

  • Micron-level filtration accuracy

  • OEM & custom sizing support

  • Global logistics & technical consultation

  • Proven durability across global industrial sectors


Frequently Asked Questions (FAQ)

Q1: Is this filter suitable for high air flow?
Yes, the 150-micron pore structure supports high air throughput with minimal resistance, ideal for blowers and compressors.

Q2: Can it be used in outdoor or humid environments?
Yes, sintered bronze is corrosion-resistant and temperature-tolerant, making it ideal for both indoor and outdoor use.

Q3: Can this be cleaned and reused?
Absolutely. This filter can be flushed with air or solvent, or cleaned ultrasonically, and reused multiple times.

Q4: Is it suitable for oil mist or wet air?
Yes, but depending on oil content, cleaning frequency may increase. The bronze surface withstands light oil exposure without degradation.

Q5: Can DALON produce this in other micron sizes?
Yes. DALON offers custom micron ratings and cone sizes to meet your specific application requirements.

Additional image 2
high-performance SINTERED BRONZE AIR FILTER CONE 32X41X46 150MICRON, designed for efficient and reliable air filtration in a compact, cone-shaped form. This filter combines robust sintered bronze construction with a conical design, ideal for applications demanding precise particulate removal while maximizing airflow.

Applications & Industries

Filter Silencing Applications Filter Silencing Applications

Chemical & Manufacturing

  • CHEMICAL INDUSTRIES
  • SEMICONDUCTOR
  • SCIENTIFIC INSTRUMENT
  • PHARMACEUTICAL
  • POLYMER FILTRATION
  • GAS AND LIQUID FILTRATION
Fluidization Applications Filter Silencing Applications

Common Applications

  • SILENCING
  • SPARGING
  • FLUIDIZATION
  • SENSOR AND VALVE PROTECTION
  • FLOW RESTRICTION
  • HANDLING OF BULK MATERIAL
Filter Applications

Industry Solutions

The versatility of BRONZE FILTER CONE 32X41X46 150MICRON makes them ideal for various industrial applications. Key industries that benefit from these sintered bronze filters include:

Chemical Processing:
- Filtration of process chemicals, catalysts, and reaction media in chemical manufacturing.
Semiconductor:
- Ultra-pure filtration for process gases and chemicals in chip manufacturing.
Pharmaceutical:
- Critical filtration in drug manufacturing and sterile processing applications.
Industrial Machinery:
- Hydraulic and lubrication system filtration for optimal equipment performance.
Gas Processing:
- Filtration and flow control in gas distribution and processing systems.
