Premium Quality Sintered IronBushing
| Manufacturer | DALON |
| Material | Iron Base / SAE 863 |
| Type | FLANGE BUSHING |
| Working Temperature ?/td> | from -20°C to +120°C |
| Product Code | SIB304050520 |
| Density (g/cm³) | from 6.0 to 6.8 |
| HS Code | 84839000 |
| Hardness | 35 ~ 50 HRB |
| Static Load (Mpa) | 850 kg/cm² |
| Max Speed (m/s) | 5 m/s |
| Max PV (dry) | 1.0 – 1.5 MPa·m/s |
| I.D.(d) | 30 |
| I.D. (d1) | |
| O.D. (D) | 40 |
| O.D. (D1) | |
| Length (L) | 20 |
| Flange Dia. (fd) | 50 |
| Flange Thickness (fl) | 5 |
| General Tolerance | E7 r7 js13 |
| Weight(ref)/Gram | 99.00 |
| Minimum Order Qty | 40KGS |
DALON’s oil embedded sleeve iron bearing is a high-performance sintered iron flanged bushing, designed for medium to heavy-load rotating applications requiring excellent wear resistance and consistent self-lubrication. This specific model—SINTERED IRON FLANGE BUSHING 30×40×50×5×20—features a flange for secure mounting and axial positioning, along with oil impregnation that ensures maintenance-free operation over extended cycles.
The bearing is manufactured using powder metallurgy technology, which creates a porous structure that is vacuum-impregnated with lubricating oil during production. This design guarantees consistent internal lubrication throughout the bushing's life span, even in environments with minimal external maintenance.
Type: Oil Embedded Flanged Bushing
Material: Sintered Iron (with graphite-based oil impregnation)
Size: 30 mm ID × 40 mm OD × 50 mm Flange OD × 5 mm Flange Thickness × 20 mm Total Length
Self-lubricating: No need for external lubrication during normal operation
Good dimensional stability: Suitable for repetitive motion and load-carrying conditions
Cost-effective: Long service life with minimal maintenance
Mounting: Flanged design for easy assembly and secure axial positioning
Industrial machinery and conveyors
Agricultural equipment and implements
Construction tools and drive systems
Automotive linkages and rotating shafts
OEM custom bushing applications
DALON is a trusted ISO 9001:2015-certified manufacturer of sintered metal bearings and bushings. We provide:
OEM customization: From material grade to pore size, flange dimensions, and oil types
In-house tooling design: Fast prototyping and private-label manufacturing
Reliable delivery:
Standard mold products: Delivery in approx. 30 days
Custom-designed products (including mold design): Delivery in 35–40 days
Flexible MOQ: For custom bushing requirements, contact DALON for evaluation and support
Q1: What is the benefit of oil embedding in sintered iron bushings?
Oil embedding provides continuous internal lubrication, reducing friction and extending service life without external greasing.
Q2: Can this bearing be used in vertical installations?
Yes. The flanged design ensures stable axial placement, making it suitable for both horizontal and vertical mounting.
Q3: How is the flange dimension determined in your size specification?
Our sizing format follows: ID × OD × Flange OD × Flange Thickness × Total Length, ensuring accurate product selection.
Q4: Are these bearings suitable for high-load applications?
Yes. Sintered iron with graphite oil impregnation supports moderate to heavy radial loads in dynamic systems.
Q5: Can I request a different size or custom flange shape?
Absolutely. DALON offers full customization including special flange designs, tolerances, and oil types per your application's needs.
Q6: How does this product compare with bronze bushings?
While bronze offers slightly better corrosion resistance, sintered iron bushings are more cost-effective for high-load industrial applications.
Q7: What industries typically use this bushing?
Used in industrial machinery, agricultural systems, drive components, and custom OEM assemblies requiring durable and maintenance-free solutions.
The versatility of SINTERED IRON FLANGE BUSHING 30X40X50X5X20 makes them ideal for numerous applications, including:
SINTERED IRON FLANGE BUSHING 30X40X50X5X20 are engineered for heavy-duty applications where superior load capacity and durability are essential. They offer exceptional wear resistance, high load-bearing capabilities, and long service life, making them the ideal choice for demanding industrial applications. Experience the strength and reliability of SINTERED IRON FLANGE BUSHING 30X40X50X5X20, designed to meet the rigorous demands of heavy machinery and industrial equipment.
Our professional team is ready to assist with your inquiry for this 30 mm Oil-Embedded Iron Flange Bearing – Sintered Type.
