STEEL FILTER DISC 47X2 40MICRON

DALON’s STEEL FILTER DISC 47×2 40MICRON is a durable, mid-precision sintered stainless steel 316 filter designed for gas, air, and fluid filtration in industrial applications. Constructed from high-purity SS316L stainless steel powder, the disc is formed via sintering to create a uniform porous structure that delivers consistent 40-micron filtration with high mechanical strength and corrosion resistance.

With a 47 mm diameter and 2 mm thickness, this filter disc is suitable for use in flow systems, process control, gas distribution, or chemical protection lines. Its rigid design provides low-pressure drop, smooth flow, and long service life—even under elevated temperatures, pressure fluctuations, or exposure to aggressive chemicals.

The disc is fully reusable, supporting ultrasonic, chemical, or reverse-flow cleaning without deformation or performance loss.

Key Features:

• Material: Sintered Stainless Steel 316L

• Size: 47 mm diameter × 2 mm thickness

• Filtration Rating: 40 microns

• Structure: Uniform porous sintered metal

• Corrosion Resistance: Excellent for acidic or solvent-rich media

• Thermal Resistance: Ideal for high-temperature systems

• Mechanical Stability: Crush-resistant and vibration-tolerant

• Reusable: Long life with multiple cleaning cycles

• Application Versatility: For air, gas, fuel, chemical, or solvent systems

Common Applications:

• Gas and air purification modules

• Chemical process filtration

• Fuel system pre-filtration

• Vent and exhaust filtration

• Pressure regulator protection

• Flow meters and test equipment

FAQ – Frequently Asked Questions

Q1: What does a 40-micron sintered 316 filter do?
It captures medium-sized particles from gas or liquid streams while allowing steady flow, used in both protection and pre-filtration roles.

Q2: Can the filter disc be reused?
Yes, it can be cleaned and reused repeatedly without loss of pore integrity or performance.

Q3: Why use SS316L for filtration?
SS316L offers high corrosion resistance, thermal durability, and mechanical strength, even in harsh industrial settings.

Q4: How is a sintered filter different from mesh or pleated filters?
Sintered filters are formed into a rigid, porous matrix with fixed pore sizes—resisting deformation, shedding, and clogging better than mesh.

Q5: Can this disc be customized?
Absolutely. DALON can provide customized sizes, pore ratings, thicknesses, and even threaded or flanged designs on request.
