STEEL FILTER TUBE 10X16X20 30MICRON

DALON’s STEEL FILTER TUBE 10×16×20 30MICRON is a high-performance sintered stainless steel 316 filter tube engineered for medium-particle filtration in compact air, gas, and fluid systems. Made from 316L stainless steel powder, this filter delivers a precise 30-micron filtration rating, ensuring protection from contaminants while maintaining a stable flow.

With a 10 mm inner diameter, 16 mm outer diameter, and 20 mm length, this tube fits easily into tight spaces and is ideal for OEM systems, sensors, fuel injectors, and control valve inlets. The sintered body offers depth filtration, trapping particles within the porous matrix for improved efficiency.

The filter is washable and reusable, supporting ultrasonic cleaning, solvent rinsing, or backflushing, making it a cost-effective choice for long-term use in demanding environments.

Key Features:

• Material: Sintered Stainless Steel 316L

• Size: 10 mm ID × 16 mm OD × 20 mm length

• Filtration Rating: 30 microns

• Structure: Tube-shaped porous sintered metal

• Performance: High-pressure and corrosion-resistant

• Reusability: Designed for multiple cleaning cycles

• Applications: Air, gas, fuel, and low-viscosity fluids

• Fitment: Ideal for compact housings or port-mounted systems

Common Applications:

• Fuel and vapor system filtration

• Sensor protection in analytical equipment

• Air and gas filtration in pneumatic tools

• Hydraulic control valve filtration

• Emission control and breather vent filters

• Lab equipment and micro-instrumentation

FAQ – Frequently Asked Questions

Q1: What kind of particles does a 30µm filter remove?
It filters out medium-sized particles (≥30 microns), suitable for general protection and pre-filtration.

Q2: Can this filter be reused?
Yes. It is fully reusable and supports multiple cleaning methods.

Q3: Why use sintered stainless steel over mesh?
Sintered filters offer deeper, more consistent filtration and higher mechanical strength.

Q4: Is it suitable for high-pressure or corrosive systems?
Absolutely. Made from 316L stainless steel, it's ideal for demanding chemical and pressure environments.

Q5: Can I order custom sizes or filtration ratings?
Yes. DALON offers full customization to meet your system requirements.
