Premium Quality Sintered Steel Filter
| I.D.(d) | 13.5 |
| I.D. (d1) | |
| O.D. (D) | 59.5 |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL FILTER CARTRIDGE 13.5×59.5 is a durable and efficient air filtration solution crafted from high-quality 316L sintered stainless steel. Designed for gas filtration applications, it offers uniform porosity, excellent flow capacity, and strong resistance to corrosion and thermal stress.
With a 13.5 mm diameter and 59.5 mm length, this cartridge filter provides medium-depth filtration for dust, aerosols, fine particles, and other airborne contaminants. The sintered metal structure ensures non-migrating media, stable pore distribution, and compatibility with high-pressure and high-temperature environments.
This cartridge is fully reusable, making it ideal for applications where cleaning and long-term performance are required. It is commonly used in compressed air systems, vacuum pumps, gas sampling ports, and instrument air intakes.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel 316L |
| Outer Diameter (OD) | 13.5 mm |
| Length | 59.5 mm |
| Filtration Type | Depth filtration |
| Typical Pore Range | Customizable (e.g., 10–50 micron) |
| Reusability | Yes – ultrasonic, backflush, solvent safe |
| Operating Temp Range | –200°C to +600°C |
| Pressure Compatibility | Suitable for compressed gas systems |
| Corrosion Resistance | Excellent – acids, solvents, oxidizers |
Compressed air pre-filtration for pneumatic systems
Air inlet filters for sensors and transmitters
Vacuum equipment protection
Gas sampling or analytical instrumentation
Cleanroom or sterile air filtration
Fermentation and bioprocess air filtration
Dust/oil mist removal in pressurized air lines
Q1: What is this filter used for in air systems?
It is designed to remove particles, mist, and fine contaminants from compressed air, sensor inlets, or clean gas lines.
Q2: Can it be used in high-temperature environments?
Yes. 316L stainless steel handles thermal cycling up to 600°C without degrading structure or filtration performance.
Q3: Is this filter reusable?
Absolutely. It is cleanable via backflush, ultrasonic cleaning, or solvent rinse, making it cost-efficient for industrial reuse.
Q4: What’s the typical filtration rating?
Customizable from 10 to 50 microns, depending on application needs. Default configuration suits general air filtration.
Q5: Can it be integrated into standard housings?
Yes. DALON supports OEM adaptation, including dimensional customization and fitting designs for inline or threaded use.
The versatility of SINTERED STAINLESS STEEL FILTER CARTRIDGE 13.5X59.5 makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
Our professional team is ready to assist with your inquiry for this Precision Air Filter – 316L Cartridge for Clean Gas Lines.
