Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL 316L FILTER 100MICRON is a robust, high-capacity industrial filter element engineered for reliable particle retention in demanding gas, air, and fluid handling systems. Designed using sintered metal powder technology, this filter achieves uniform 100-micron nominal filtration across its entire depth structure, ideal for high-throughput applications.
Constructed from 316L stainless steel, the filter combines excellent corrosion resistance, mechanical integrity, and thermal stability. It is suitable for use in harsh industrial environments including chemical plants, water treatment systems, power generation, food processing, and hydraulic circuits.
The sintered matrix allows for depth filtration, where particles are retained within the porous body, preventing surface clogging and ensuring longer operational life. Unlike disposable media, this filter is fully cleanable and reusable, enabling cost savings and sustainable operation.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel 316L |
| Filtration Rating | 100 micron (nominal) |
| Media Type | Depth filtration |
| Reusability | Yes – ultrasonic, solvent or backflush |
| Temperature Range | –200°C to +600°C |
| Chemical Resistance | Excellent – acids, solvents, gases |
| Pressure Resistance | High – suitable for industrial use |
| Common Formats | Disc, tube, cartridge, cap |
Industrial air and gas pre-filtration
Cooling fluid return filters in process equipment
Chemical processing lines (e.g., acids, bases, solvents)
Hydraulic oil reservoir protection
Paint, ink, or adhesive batch filtration
Food-grade gas line filtration (e.g., CO₂ or N₂)
Power plant or refinery fluid conditioning
CIP (Clean-in-Place) filtration in bottling or pharma systems
Q1: Is this filter meant for high-flow or fine filtration?
This 100-micron version is optimized for high-flow pre-filtration, removing coarse particles before secondary or polishing filtration stages.
Q2: Can it be cleaned and reused in industrial settings?
Yes. It is fully cleanable via solvent rinsing, backflushing, ultrasonic bath, or chemical soaking depending on contamination type.
Q3: Is it suitable for high temperatures or corrosive fluids?
Absolutely. Made from 316L stainless steel, it performs reliably in aggressive chemical and thermal conditions.
Q4: What formats are available for this filter?
DALON provides various geometries including discs, tubes, caps, and cartridges to match system requirements.
Q5: Can this filter be customized for OEM equipment?
Yes. Dimensions, filtration grades, and connection styles (threaded, flanged, welded) can all be tailored upon request.
The versatility of SINTERED STAINLESS STEEL 316L FILTER 100MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
