STEEL FILTER CAP M12 X14X60 10MICRON

Premium Quality Sintered Steel Filter

DALON CAP FILTER

Product Overview

Product Specifications

Manufacturer DALON
Material POROUS STAINLESS STEEL
Type CAP FILTER
Reference Drawing
Product Code DLP201712387
Pore Pitch 10MICRON
HS Code 84219990
RoHS Compliant
REACH Compliant

Technical Drawings & Dimensions

sintered filter element Technical Drawing

Product Dimensions

I.D.(d)
I.D. (d1)
O.D. (D)
O.D. (D1)
Length (L)
Flange Dia. (fd)
Flange Thickness (fl)
General Tolerance ±0.3mm
Weight(ref)/Gram 0.00
Minimum Order Qty 0
All dimensions in millimeters (mm) unless otherwise specified.

Product Description

Sintered Filter Element – Precision Built by DALON

STEEL FILTER CAP M12 X14X60 10MICRON Additional image 1

DALON’s Sintered Steel Filter Element M12×14×60 (10 Micron) is a high-precision inline filtration component engineered to offer reliable particulate removal in pressurized air, gas, or fluid applications. Manufactured from high-density sintered stainless steel, this filter cap integrates strength, chemical resistance, and uniform pore distribution into a compact and easily mountable design.

With a 10-micron filtration rating, this element is ideal for blocking fine particles such as dust, rust, carbon debris, or micro-scale contaminants that could damage or clog sensitive valves, sensors, pumps, or dosing components.

The M12 male thread allows for direct installation into threaded housings or fittings, making it well-suited for use in automation control systems, laboratory gas lines, or chemical fluid dispensing systems where durability and clean flow are essential.


Key Specifications

  • Filtration Rating: 10 microns (nominal)

  • Thread Size: M12 male

  • Dimensions:

    • Outer Diameter: 14 mm

    • Total Length: 60 mm

  • Material: Sintered stainless steel (SS316 or SS316L optional)

  • Operating Pressure: Suitable for medium to high-pressure systems

  • Temperature Range: Up to 500°C

  • Design: Threaded filter cap with sealed end

  • Cleaning: Washable and reusable with compressed air, solvent, or ultrasonic methods


Applications

  • Inline gas and air filtration in pneumatic actuators or solenoid valves

  • Liquid filtration in dosing or metering pumps

  • Clean fluid delivery in analytical or laboratory instruments

  • Protection for flow regulators, sensors, and injectors

  • Pressure equalization or breather vents in industrial control systems

  • Filtration in chemical, medical, or food-grade environments (SS316L)


Why Choose DALON

DALON is a global provider of high-performance sintered filter elements, serving OEMs in automation, fluid control, environmental monitoring, and more. Each product is developed under ISO 9001:2015 standards to meet rigorous operational and safety requirements.

  • Custom Engineering: Full support for tailored dimensions, threads, micron ratings, and materials

  • Fast Delivery: Existing mold-based products ship within 30 days; customized solutions delivered in 35–40 days (including tooling)

  • Flexible Quantities: MOQ varies by customization level—contact DALON directly for details

  • Comprehensive Support: CAD drawings, flow simulation data, and prototyping services available


FAQ – Frequently Asked Questions

Q1: What does a 10-micron sintered filter remove?
It captures fine particulate contaminants such as rust flakes, dust, and micro-debris, protecting downstream components in precision fluid systems.

Q2: Can this sintered filter be cleaned and reused?
Yes. It is designed to support multiple cleaning cycles using ultrasonic baths, solvents, or reverse flow flushing with air or gas.

Q3: What media is this filter compatible with?
This sintered filter cap is ideal for clean air, nitrogen, inert gases, water-based fluids, and many chemicals, especially when made with SS316L.

Q4: Is the M12 thread a common connection?
Yes, M12 is a standard metric thread used in many pneumatic and sensor applications, offering secure and leak-resistant installation.

Q5: How do I select the right micron rating?
Choose based on your contamination control target. 10 microns is ideal for protecting fine control components and instrumentation.

Q6: What do people also ask?

  • What is a sintered filter element used for?
    It is used to trap fine particles in gas or fluid systems while maintaining flow. Ideal for industrial automation, pneumatic systems, and lab setups.

  • How long does a sintered filter last?
    With proper cleaning, sintered metal filters can be reused many times, often lasting for months or years in non-corrosive environments.

  • What are the benefits of stainless steel sintered filters?
    They offer mechanical strength, temperature resistance, and chemical compatibility—making them ideal for demanding industrial environments.

  • Is this filter suitable for high temperatures?
    Yes. Stainless steel sintered filters can operate at temperatures up to 500°C, depending on system conditions.

Additional image 2
STEEL FILTER CAP M12×14×60 mm – sintered filter element with 10µm precision for reliable air, fluid, or gas filtration in threaded inline systems.

Applications & Industries

Filter Silencing Applications Filter Silencing Applications

Chemical & Manufacturing

  • CHEMICAL INDUSTRIES
  • SEMICONDUCTOR
  • SCIENTIFIC INSTRUMENT
  • PHARMACEUTICAL
  • POLYMER FILTRATION
  • GAS AND LIQUID FILTRATION
Fluidization Applications Filter Silencing Applications

Common Applications

  • SILENCING
  • SPARGING
  • FLUIDIZATION
  • SENSOR AND VALVE PROTECTION
  • FLOW RESTRICTION
  • HANDLING OF BULK MATERIAL
Filter Applications

Industry Solutions

The versatility of STEEL FILTER CAP M12 X14X60 10MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:

Chemical & Pharmaceutical:
- For precise filtration in chemical processing, pharmaceutical manufacturing, and laboratory applications.
Semiconductor & Electronics:
- In clean room environments and semiconductor manufacturing where high-purity filtration is critical.
Manufacturing & Processing:
- For industrial gas and liquid filtration in manufacturing processes and production lines.
Water & Waste Treatment:
- In water purification systems and wastewater treatment where reliable filtration is essential.
Air & Gas Systems:
- For air filtration, gas distribution, and pneumatic systems requiring precise flow control.
