SINTERED PLASTIC FILTER CONE 15X300 40MICRON

40µm Sintered Plastic Cone Air Filter – 15×300 mm for Large-Area Ventilation

DALON’s 40µm conical air filter, made from high-quality sintered polyethylene (PE), is designed for large-area, low-pressure air filtration where high airflow capacity and particulate control are required. Its tapered cone structure (15 mm base × 300 mm length) significantly expands the effective surface area while maintaining low resistance and stable flow, making it ideal for use in:

• Pneumatic equipment

• Industrial ventilation

• Air intake and exhaust ports

• HVAC systems

• Cleanroom machinery

Key Features

• Filtration rating: 40 microns (nominal)

• Dimensions: 15 mm base diameter × 300 mm length

• Material: Sintered polyethylene (PE)

• Expanded filtration area due to conical geometry

• Moisture-resistant and chemically stable

• Washable, reusable, and lightweight

• Precision-formed for structural consistency

Typical Applications

• Air intake protection in blowers, compressors, or automation modules

• Exhaust air filtration in enclosures or control panels

• Ventilation and pressure equalization in machinery housings

• HVAC filter components in humid or dusty environments

• Inline filters for pneumatic tools or fluid transfer units

Why Choose DALON Cone Filters?

With over 20 years of experience in sintered filter manufacturing, DALON delivers both standard and OEM-customized filtration solutions. Our filters are produced under ISO 9001:2015-certified systems, ensuring:

• Uniform pore distribution

• Dimensional accuracy

• Mechanical strength

• OEM fit for housing or cartridge systems

We support customization for base diameter, length, taper angle, pore size, and material type (PE, PP, PVDF), ensuring seamless integration into your air filtration system.

FAQ – Frequently Asked Questions

Q1: What particles can the 40µm cone filter remove?
It captures coarse airborne particles such as dust, fibers, and process debris while allowing free airflow in large-volume systems.

Q2: Why use a cone shape instead of a disc or tube?
The cone shape provides greater surface area, reduces localized airspeed, and improves filtration efficiency without increasing footprint.

Q3: Can this filter be reused?
Yes. It can be washed and reused multiple times. Recommended cleaning includes water rinsing, mild detergent soaking, or air blow-out.

Q4: Is it suitable for outdoor or humid applications?
Yes. PE is resistant to moisture and mild chemical exposure, making it suitable for semi-outdoor or humid conditions.

Q5: Can the dimensions be customized?
Absolutely. DALON offers full OEM customization, including cone length, base diameter, wall thickness, micron rating, and mounting/bonding style.

Q6: What industries use cone-shaped plastic air filters?
Common in automation systems, industrial ventilation, lab devices, pneumatics, HVAC modules, and packaging machinery.
