PLASTIC FILTER CARTRIDGE NPT 1/8 5MICRON

Premium Quality Plastic Filter

DALON FILTER CARTRIDGE

Product Overview

Product Specifications

Manufacturer DALON
Material POROUS PLASTIC
Type FILTER CARTRIDGE
Reference Drawing
Product Code DLP202205103
Pore Pitch 5MICRON
HS Code 84219990
RoHS Compliant
REACH Compliant

Technical Drawings & Dimensions

micron filter Technical Drawing

Product Dimensions

I.D.(d)
I.D. (d1)
O.D. (D)
O.D. (D1)
Length (L)
Flange Dia. (fd)
Flange Thickness (fl)
General Tolerance ±0.3mm
Weight(ref)/Gram 0.00
Minimum Order Qty 0
All dimensions in millimeters (mm) unless otherwise specified.

Product Description

High-Efficiency Micron Filter – 5µm Plastic NPT Cartridge

PLASTIC FILTER CARTRIDGE NPT 1/8 5MICRON Additional image 1

Plastic Micron Filter Cartridge – 5µm, NPT 1/8" Thread

DALON’s 5µm plastic micron filter cartridge, featuring a standard NPT 1/8" male thread, provides high-efficiency filtration in compact pneumatic and fluidic systems. Crafted from sintered polyethylene (PE), this cartridge offers low pressure drop, uniform pore structure, and reliable performance across air, gas, and liquid applications. Its threaded design ensures secure and easy installation into regulators, valves, dosing pumps, and sample lines.

The 5-micron nominal pore size effectively captures dust, rust, fibers, and other micro-contaminants, helping protect sensitive downstream components from clogging or wear.


Key Features

  • Filtration rating: 5 microns (nominal)

  • Connection type: NPT 1/8" male thread

  • Material: Sintered polyethylene (PE)

  • Moisture-, chemical-, and corrosion-resistant

  • Washable and reusable for long service life

  • Compact, lightweight, and ideal for OEM integration


Applications

  • Air and gas filtration in pneumatic automation systems

  • Water filtration in precision dosing equipment

  • Protection for flow sensors and control valves

  • Sample line filtration in environmental/laboratory instruments

  • Inline filters for chemical dispensers and compact machines


Why Choose DALON

DALON is a globally trusted ISO 9001:2015-certified manufacturer of sintered plastic filters. Our NPT 1/8" filter cartridges are widely used in OEM assemblies requiring reliable filtration and space-saving design. We offer full OEM customization, including pore size, thread type, cartridge length, color identification, and material grades.


FAQ – Frequently Asked Questions

Q1: What does a 5µm plastic micron filter remove?
It captures fine particles such as dust, rust, fibers, and small suspended solids from air, gas, or fluid streams.

Q2: Is this filter suitable for both gases and liquids?
Yes. It’s compatible with clean air, compressed gases, potable water, and many neutral fluids.

Q3: Is the filter reusable?
Absolutely. It can be cleaned with water, compressed air, or mild solvents, depending on the application.

Q4: What pressure can this filter handle?
It is designed for low to medium-pressure systems. For higher-pressure applications, reinforced designs are available.

Q5: Is NPT 1/8" a universal thread?
Yes. It fits all standard NPT 1/8" female-threaded housings and components.

Q6: What industries use this filter?
Commonly used in industrial automation, medical dosing, lab analysis systems, fluid controllers, and pneumatic equipment.

Additional image 2
PLASTIC FILTER CARTRIDGE NPT 1/8 – 5µm sintered PE filter for gas, air, or fluid filtration with standard NPT thread interface.

Applications & Industries

Filter Silencing Applications Filter Silencing Applications

Chemical & Manufacturing

  • CHEMICAL INDUSTRIES
  • SEMICONDUCTOR
  • SCIENTIFIC INSTRUMENT
  • PHARMACEUTICAL
  • POLYMER FILTRATION
  • GAS AND LIQUID FILTRATION
Fluidization Applications Filter Silencing Applications

Common Applications

  • SILENCING
  • SPARGING
  • FLUIDIZATION
  • SENSOR AND VALVE PROTECTION
  • FLOW RESTRICTION
  • HANDLING OF BULK MATERIAL
Filter Applications

Industry Solutions

The versatility of PLASTIC FILTER CARTRIDGE NPT 1/8 5MICRON makes them ideal for various industrial applications. Key industries that benefit from these plastic filters include:

Chemical & Pharmaceutical:
- For precise filtration in chemical processing, pharmaceutical manufacturing, and laboratory applications.
Semiconductor & Electronics:
- In clean room environments and semiconductor manufacturing where high-purity filtration is critical.
Manufacturing & Processing:
- For industrial gas and liquid filtration in manufacturing processes and production lines.
Water & Waste Treatment:
- In water purification systems and wastewater treatment where reliable filtration is essential.
Air & Gas Systems:
- For air filtration, gas distribution, and pneumatic systems requiring precise flow control.
