SINTERED PE FILTER SHEET 500X500X4 10MICRON

Premium Quality Plastic Filter

DALON SPECIAL DESIGN

Product Overview

Product Specifications

Manufacturer DALON
Material POROUS PLASTIC
Type SPECIAL DESIGN
Reference Drawing
Product Code DLP201508016
Pore Pitch 10MICRON
HS Code 84219990
RoHS Compliant
REACH Compliant

Technical Drawings & Dimensions

sensor filter Technical Drawing

Product Dimensions

I.D.(d)
I.D. (d1)
O.D. (D) 500
O.D. (D1) 500
Length (L) 4
Flange Dia. (fd)
Flange Thickness (fl)
General Tolerance ±0.3mm
Weight(ref)/Gram 0.00
Minimum Order Qty 0
All dimensions in millimeters (mm) unless otherwise specified.

Product Description

Cuttable 10µm Sensor Filter – Breathable PE Sheet for Devices

SINTERED PE FILTER SHEET 500X500X4 10MICRON Additional image 1

DALON’s 10µm sintered PE sensor filter sheet is a high-efficiency barrier designed for protecting sensitive electronics and sensor systems in smart, environmental, and industrial applications. Built using sintered polyethylene (PE) with a highly uniform microporous structure, this 500 mm × 500 mm × 4 mm sheet delivers reliable dust, splash, and particulate shielding while maintaining low airflow resistance—essential for pressure-based or gas-sensitive sensing devices.

Its precision-engineered pore distribution allows for effective air and gas exchange, making it ideal for devices that require ventilation without contamination. The material is both chemically inert and hydrophobic, ensuring long-term durability even in high-humidity or outdoor conditions. Whether applied as a venting membrane, filter interface, or custom-cut component, this sheet enhances sensor lifespan and performance reliability.

Thanks to its machinable design, the sheet can be easily trimmed, CNC-cut, or die-punched into various sizes and geometries, supporting flexible integration in OEM designs or field retrofits. Its low-pressure drop performance ensures no compromise on sensor response time or data accuracy.


Key Features

  • Filtration Rating: 10 microns (nominal)

  • Sheet Dimensions: 500 mm × 500 mm × 4 mm

  • Material: Sintered polyethylene (PE)

  • Uniform microporous structure for stable airflow

  • Corrosion-resistant, moisture-proof, and UV-stable

  • Suitable for custom fabrication (cutting, shaping, forming)

  • Maintains integrity in high-humidity and outdoor environments

  • Lightweight and non-conductive—safe for electronics


Applications

  • Venting in barometric, CO₂, and humidity sensors

  • Environmental sensor enclosures and smart IoT housings

  • Control panels, industrial automation, and HVAC equipment

  • Protective splash-resistant covers in outdoor monitoring stations

  • Medical instruments and diagnostic device filtration

  • Custom air inlets, vents, and membranes in compact modules


Why Choose DALON

DALON is a trusted ISO 9001:2015-certified manufacturer specializing in sintered plastic filtration media. Our sensor protection filter sheets are produced with tight dimensional tolerances and consistent porosity, offering dependable performance across varied industries.

  • Customization available: sheet size, pore rating, thickness, and color

  • Optional hydrophobic or hydrophilic surface treatments

  • Short lead time: 30 days for existing molds, 35–40 days for new designs including mold tooling

  • Low MOQ support – contact DALON for tailored solutions

  • Full design support for integration into sensor or air control assemblies


FAQ – Frequently Asked Questions

Q1: What does a 10µm sensor filter sheet block?
It blocks fine dust, pollen, splash water, and airborne particles, protecting sensor openings while maintaining airflow.

Q2: Can this sheet be trimmed or cut into smaller sizes?
Yes. The sheet can be cut using scissors, utility knives, die-cutting, or CNC without affecting its filtration properties.

Q3: Is this filter suitable for outdoor electronics?
Yes. It is UV-stable, water-resistant, and chemically inert—ideal for outdoor, industrial, or high-humidity settings.

Q4: Can I use this sheet with airflow sensors or barometric modules?
Absolutely. It allows for consistent gas or air exchange, making it suitable for all pressure-sensitive or gas-sensing devices.

Q5: Is the material safe for use in electronics?
Yes. Sintered PE is non-conductive, anti-static, and chemically inert, ensuring no interference with sensitive electronics.

Q6: What’s the lead time for custom sheet sizes or pore ratings?
Typically 35–40 days including tooling. Existing formats can ship within 30 days.

Q7: What industries typically use this filter type?
It’s widely used in IoT devices, smart sensors, HVAC systems, medical electronics, lab equipment, and environmental monitoring units.

Additional image 2
Ensure reliable sensor performance with this 10µm breathable PE sheet – cut to size for clean, durable air filtering in electronics.

Applications & Industries

Filter Silencing Applications Filter Silencing Applications

Chemical & Manufacturing

  • CHEMICAL INDUSTRIES
  • SEMICONDUCTOR
  • SCIENTIFIC INSTRUMENT
  • PHARMACEUTICAL
  • POLYMER FILTRATION
  • GAS AND LIQUID FILTRATION
Fluidization Applications Filter Silencing Applications

Common Applications

  • SILENCING
  • SPARGING
  • FLUIDIZATION
  • SENSOR AND VALVE PROTECTION
  • FLOW RESTRICTION
  • HANDLING OF BULK MATERIAL
Filter Applications

Industry Solutions

The versatility of SINTERED PE FILTER SHEET 500X500X4 10MICRON makes them ideal for various industrial applications. Key industries that benefit from these plastic filters include:

Chemical & Pharmaceutical:
- For precise filtration in chemical processing, pharmaceutical manufacturing, and laboratory applications.
Semiconductor & Electronics:
- In clean room environments and semiconductor manufacturing where high-purity filtration is critical.
Manufacturing & Processing:
- For industrial gas and liquid filtration in manufacturing processes and production lines.
Water & Waste Treatment:
- In water purification systems and wastewater treatment where reliable filtration is essential.
Air & Gas Systems:
- For air filtration, gas distribution, and pneumatic systems requiring precise flow control.
