Premium Quality Sintered Bushing
| I.D.(d) | 7 |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | 15 |
| Length (L) | 10.5 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | F7 r7 js13 |
| Weight(ref)/Gram | 10.00 |
| Minimum Order Qty | 40KGS |
DALON’s 7×15×10.5 mm sintered bronze spherical bushing bearing offers high-precision alignment and self-lubrication for compact mechanical and electromechanical systems. Featuring a spherical outer contour, this bronze bushing automatically compensates for minor misalignments between shaft and housing, ensuring smooth motion, reduced wear, and quiet operation.
The porous bronze body is oil-impregnated during the sintering process, delivering maintenance-free lubrication and optimal performance in rotary or oscillating motion applications.
Dimensions:
• Inner Diameter (ID): 7 mm
• Outer Diameter (OD): 15 mm
• Total Length: 10.5 mm
Material: Oil-impregnated sintered bronze
Design: Spherical self-aligning outer shape
Performance Highlights:
• Maintenance-free lubrication
• Excellent vibration absorption
• High dimensional stability and corrosion resistance
• Easy to press-fit into housings
Electric motors and servo drives
Compact actuator and gearbox systems
Precision automation and robotics
Medical devices and lab instruments
Automotive and agricultural machinery
As an ISO 9001:2015-certified supplier, DALON specializes in powder metallurgy bearings including spherical bronze bushings. Our sintered bronze bushing bearings are engineered for OEMs seeking compact, durable, and maintenance-free solutions with excellent alignment capability. All components are manufactured with tight tolerance control and uniform oil saturation to ensure long-lasting performance.
Customization is available for special tolerances, sizes, lubricant types, and packaging for your assembly line or product integration needs.
Q1: What advantages does the spherical outer design provide?
It enables self-alignment within a fixed housing, reducing stress on connected components and improving mechanical efficiency.
Q2: Does this bushing require external lubrication?
No. It is oil-impregnated and functions as a self-lubricating bearing under normal operating conditions.
Q3: Is this suitable for continuous rotational use?
Yes. It is well-suited for light-to-medium load rotation or oscillation in small equipment.
Q4: What are the environmental limitations of sintered bronze bushings?
They are best used in dry or mildly humid environments. For high-moisture or chemical exposure, contact us for alternative materials.
Q5: Can this bearing be customized for specific applications?
Absolutely. DALON offers complete OEM support for size, tolerance, lubricant, and mounting variations.
The versatility of SINTERED BRONZE SPHERICAL BUSHING 7X15X10.5 makes them ideal for numerous applications, including:
SINTERED BRONZE SPHERICAL BUSHING 7X15X10.5 are engineered for demanding applications where traditional lubrication methods are impractical. They provide exceptional performance, durability, and cost-effectiveness, making them the preferred choice across various industries. Experience the reliability and efficiency of SINTERED BRONZE SPHERICAL BUSHING 7X15X10.5, designed to meet your specific application requirements.
