Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL AISI316L FILTER DISC 20×2 AS DRAWING 100664 80MICRON is a precision-engineered sintered mesh disc manufactured according to customer-specific drawing 100664. Made from AISI316L stainless steel, this disc combines the rigidity of sintered construction with the uniform filtration capabilities of stainless mesh, providing a stable and cleanable solution for gas, air, and fluid systems.
With 20 mm diameter and 2 mm thickness, the disc is compact yet robust, designed for insertion into tight assemblies such as valve seats, flow control units, or chemical dosing modules. The 80-micron nominal pore size offers coarse but reliable protection against particulate contamination in both gaseous and liquid media.
DALON’s sintered mesh discs are fully customizable to your drawings, ensuring seamless integration into OEM equipment and lab-grade setups. The structure resists high pressure, extreme temperature, and harsh chemicals, while allowing repeated cleaning and reuse.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel AISI316L |
| Outer Diameter (OD) | 20 mm |
| Thickness | 2 mm |
| Pore Size | 80 micron (nominal) |
| Filtration Type | Mesh-style sintered depth filtration |
| Drawing Reference | Custom – Drawing No. 100664 |
| Cleanability | Yes – backflush, solvent rinse, ultrasonic safe |
| Operating Temperature | –200°C to +600°C |
| Pressure Resistance | Suitable for both liquid and gas systems |
| Corrosion Resistance | Excellent – compatible with acids, bases, solvents |
OEM components in chemical dosing equipment
Air and gas flow control modules with inline filtration
Hydraulic or pneumatic circuit filter seats
Medical device or lab instrument filtration
Fuel or solvent filter elements in industrial machinery
Protective disc for sensors, nozzles, or micro-orifices
Precision filtration in chemical and process instrumentation
Q1: What does “AS DRAWING 100664” mean?
It indicates this disc is manufactured exactly to your provided technical drawing, ensuring perfect dimensional and functional fit.
Q2: Can the 80-micron rating be adjusted?
Yes. DALON offers mesh discs from 5µm to 100µm, depending on flow and contamination control needs.
Q3: Is the disc washable and reusable?
Absolutely. The sintered AISI316L structure allows multiple cleanings, extending service life significantly.
Q4: Can it withstand aggressive chemicals or solvents?
Yes. 316L stainless offers outstanding resistance to corrosion, acid, solvent, and thermal stress.
Q5: Can DALON mass-produce based on my drawing?
Yes. We support OEM and batch production fully based on your custom drawings and performance specs.
The versatility of SINTERED STAINLESS STEEL AISI316L FILTER DISC 20X2 makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
Our professional team is ready to assist with your inquiry for this Custom Drawing Filter Disc for Instrumentation & Valves.
Contact UsAll our products are manufactured according to ISO 9001 standards.
View CertificatesWe offer free design services and custom manufacturing for your specific needs.
We provide worldwide shipping for all our products with reliable delivery times.
