Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL FILTER 316L CARTRIDGE G 1" is a robust, backwashable cartridge filter engineered for demanding industrial applications. Manufactured from corrosion-resistant 316L stainless steel via a precision sintering process, it provides uniform porosity, mechanical durability, and reliable depth filtration for liquids and gases.
Fitted with a G 1" (BSPP) threaded connection, this cartridge integrates seamlessly into standard pipeline filter housings, process skids, or inline filtration systems. Its reusable design supports backflushing, CIP/SIP, and ultrasonic cleaning, extending its operational lifespan and lowering maintenance costs.
The sintered metal structure enables high throughput with filtration ratings typically ranging from 5 to 100 microns, depending on specification, making it ideal for pre-filtration, cooling circuit protection, or chemical batch processing. The rigidity of the 316L matrix allows it to maintain form even under elevated pressures and temperatures.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel 316L |
| Connection | G 1" BSPP (British Standard Pipe Parallel) |
| Filter Type | Cartridge – Cylindrical, Rigid |
| Filtration Range | 5 to 100 micron (typical, per variant) |
| Flow Direction | Inside-to-out or outside-to-in |
| Temperature Range | –200°C to +600°C |
| Reusability | Yes – Backflush, CIP, Ultrasonic Safe |
| Housing Compatibility | G 1" Female Thread |
| Pressure Rating | Suitable for medium-to-high pressure flow |
Industrial water filtration with backflushing system
Chemical line prefiltration and particle removal
CIP/SIP fluid loops in food and pharma processes
Process cooling circuits in machinery and reactors
Liquid-solid separation in dyeing or plating processes
Filtration in pumps, tanks, and inline dispensers
Solvent recovery or bulk fluid transfer lines
Q1: What makes this filter “backwashable”?
The sintered 316L metal matrix is rigid and porous, allowing fluid to reverse-flow through the element to dislodge trapped particles without damage.
Q2: How is it cleaned during operation?
It can be backflushed, or removed and cleaned via ultrasonic baths, solvent soaking, or CIP/SIP cycles.
Q3: What is the advantage of G 1" threaded design?
It provides easy connection to standard housings or piping systems, commonly found in industrial applications.
Q4: Can this cartridge handle hot or corrosive fluids?
Yes. 316L stainless steel is resistant to acids, bases, solvents, and can operate at high temperatures.
Q5: Are other micron ratings or custom sizes available?
Yes. DALON can customize filtration grade, length, diameter, and threading style upon request.
The versatility of SINTERED STAINLESS STEEL FILTER 316L CARTRIDGE G1 makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
