Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL 316L FILTER DISC 47×2 3MICRON is a precision-engineered sintered filter element designed for high-pressure gas or liquid filtration. With a nominal pore size of 3 microns and a compact flat disc profile, this product is ideal for demanding industrial applications requiring fine particle retention, structural integrity, and repeatable performance.
Made from 316L stainless steel powder and sintered into a uniform porous matrix, this disc supports stable filtration even under high pressure differentials. Its compact dimensions—47 mm in diameter and 2 mm thick—make it ideal for instrument ports, valve blocks, or inline filtration where space is limited but pressure and precision are critical.
316L stainless steel offers excellent corrosion resistance, thermal stability, and mechanical strength. The filter disc is fully cleanable and supports repeated use in high-value systems, making it an ideal long-term solution for instrumentation, laboratory systems, compressed gases, hydraulic circuits, and chemical processing.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel 316L |
| Outer Diameter (OD) | 47 mm |
| Thickness | 2 mm |
| Filtration Rating | 3 micron (nominal) |
| Porosity Type | Depth filtration |
| Media Cleanability | Reusable, ultrasonic/backflush |
| Temperature Range | –200°C to +600°C |
| Pressure Resistance | High – for compressed and hydraulic systems |
Compressed gas line particulate filtration
High-pressure hydraulic circuit protection
Sample gas inlet filters for analyzers
Valve seat protection in process systems
Pneumatic control unit filtration
Instrumentation panel gas flow filters
Critical fuel or solvent line protection
Q1: What is this stainless filter disc used for?
It’s used for precise, fine-particle filtration in high-pressure gas, liquid, or hydraulic systems where compact, durable filters are needed.
Q2: Is 3 micron suitable for instrumentation filtration?
Yes. 3µm is ideal for protecting sensitive components such as flow meters, pressure sensors, and pneumatic valves.
Q3: Can it handle high differential pressure?
Yes. The sintered 316L structure is mechanically stable and resists collapse even under significant pressure gradients.
Q4: Is the filter reusable after contamination?
Absolutely. It can be cleaned using ultrasonic baths, solvent soaking, or reverse flow, depending on the application.
Q5: Can DALON customize this disc in other sizes or micron levels?
Yes. We offer full OEM customization for diameter, thickness, pore size, and even surface treatments for extreme environments.
The versatility of SINTERED STAINLESS STEEL 316L FILTER DISC 47X2 3MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
Our professional team is ready to assist with your inquiry for this Sintered Steel Disc for Fuel & Solvent Filtration Lines.
