STEEL FILTER CAP 6X10X30 5MICRON

DALON’s 5µm porous metal filter cap, sized 6×10×30 mm, is engineered for precision filtration in pneumatic, hydraulic, and gas/liquid systems that require fine particulate removal and stable flow performance. Made from sintered stainless steel, this compact filter element features a uniform microporous structure, ensuring consistent 5-micron nominal filtration accuracy and high structural strength.

This filter cap is designed for inline or terminal filtration in confined industrial spaces, offering long service life and high chemical resistance even under demanding conditions. The sintered metal construction provides superior resistance to pressure fluctuations, thermal cycling, and aggressive fluids compared to conventional screen or fiber filters.

The 5µm rating makes this product ideal for protecting valves, pumps, sensors, flow regulators, and other precision components in automation, lab systems, air compressors, or dosing equipment. It can be reused after cleaning, making it cost-effective for both OEM and aftermarket use.

Key Features

• Filtration Rating: 5 microns (nominal)

• Dimensions: 6 mm OD × 10 mm ID × 30 mm Length

• Material: Sintered stainless steel (typically SS316L)

• Uniform pore structure for consistent filtration

• Resistant to corrosion, high temperature, and pressure

• Suitable for cleanable, long-term reuse

• Compact size for easy OEM integration

Applications

• Gas and air filtration in automation or pneumatic systems

• Liquid pre-filtration in chemical dosing or lab equipment

• Protection for flow sensors, solenoids, or precision valves

• Inline filter in instrumentation or gas detection devices

• Industrial fluid control and air or gas venting

• OEM modules in control cabinets or medical systems

Why Choose DALON

With over two decades of expertise in sintered filtration, DALON delivers precision-engineered porous metal filters that meet ISO 9001:2015 standards. We support OEMs with high-performance filtration solutions designed for reliability, durability, and flexibility.

• Custom pore sizes from 0.5 to 100 microns

• Full dimensional customization including threading, caps, and housings

• Short production lead times: 30 days for standard items, 35–40 days for new custom molds

• Technical consultation available for application-specific needs

• Cleanroom-compatible and traceable production batches

FAQ – Frequently Asked Questions

Q1: What does a 5µm porous metal filter remove?
It removes fine particles such as dust, rust, and other contaminants from gases and non-viscous liquids.

Q2: Can this filter be cleaned and reused?
Yes. It can be cleaned with compressed air, ultrasonic cleaning, or solvent rinsing without degrading performance.

Q3: Is the material safe for high-temperature or corrosive use?
Yes. Made from SS316L, it performs reliably under high temperatures and in harsh chemical environments.

Q4: How does sintered metal differ from mesh filters?
Sintered metal offers depth filtration and structural integrity, making it more robust and efficient than surface-only mesh filters.

Q5: What industries use this type of filter cap?
Used in industrial automation, fluid systems, air compressors, analytical equipment, and medical instruments.

Q6: Can I order custom sizes or pore ratings?
Yes. DALON provides tailored solutions including custom sizes, connection types, and filtration grades upon request.

Q7: What is the usual delivery lead time?
Standard products: 30 days. Custom-designed items with new molds: 35–40 days, including mold development and production.
