STEEL FILTER TUBE 25X30X47 15MICRON

The STEEL FILTER TUBE 25×30×47MM 15MICRON is a sintered porous metal filter designed for demanding industrial applications. Made from high-grade stainless steel (316L or 304 optional), this cylindrical filter tube provides 15-micron absolute filtration while maintaining high flow rates and low pressure drop.

Its uniform porous structure ensures depth filtration, trapping contaminants throughout the media rather than just on the surface. The 316L material offers exceptional corrosion resistance, making it suitable for chemical processing, fuel filtration, or aggressive gas streams. With dimensions of 25 mm ID, 30 mm OD, and 47 mm length, it fits seamlessly into OEM hydraulic systems, compressed air lines, and fluid processing equipment.

Key Features:
 Reusable & cleanable (ultrasonic, backflushing, or solvent wash)
 High-temperature tolerance (–200°C to +650°C for 316L)
 No media migration – stable sintered metal structure
 Customizable (material, pore size, dimensions)

Key Specifications

Typical Applications

• Chemical processing – Aggressive fluid filtration
• Hydraulic & fuel systems – Contaminant removal
• Compressed air & gas lines – Particulate protection
• Pharmaceutical & food – Sanitary-grade filtration
• Water treatment – High-purity filtration
• Industrial OEM equipment – Custom filter solutions

FAQ

Q1: What’s the difference between 316L and 304 for this filter tube?

• 316L offers superior corrosion resistance (ideal for chemicals, seawater, acids).
• 304 is cost-effective for general-purpose water, air, and oil filtration.

Q2: Can it handle high-pressure systems?
Yes, but requires proper housing support (max ~20 bar for standalone tube).

Q3: How do I clean this porous metal filter?

• Backflushing, ultrasonic cleaning, or chemical soaking (e.g., citric acid for scale removal).

Q4: Is it suitable for food or pharmaceutical use?
Yes, with proper sanitization (316L recommended for compliance).

Q5: Can DALON customize pore size or dimensions?
Absolutely! We offer 10–100µm pore sizes and tailored lengths/diameters.
