STEEL FILTER CAP 7.6X11X20 40MICRON

DALON’s STEEL FILTER CAP 7.6×11×20 40MICRON is a compact porous stainless steel filter element designed for reliable 40-micron depth filtration in compressed air, gas, fuel, or solvent systems. Its 7.6 mm inner diameter, 11 mm outer diameter, and 20 mm total length provide a small footprint ideal for precision filtration applications in tight or embedded installations.

This filter cap is constructed using sintered 316L stainless steel powder, forming a robust porous matrix that ensures uniform particle retention, low pressure drop, and high durability under mechanical, thermal, and chemical stress. The 40µm rating targets fine-to-medium contaminants, protecting sensitive equipment or downstream filters.

It is fully cleanable and reusable, supporting maintenance with ultrasonic cleaning, solvent rinsing, or reverse flow backflushing. With excellent corrosion resistance, this filter cap is suited for harsh process environments or OEM applications where longevity and performance matter.

Key Features:

• Material: Sintered stainless steel (typically SS316L)

• Size: ID 7.6 mm × OD 11 mm × Length 20 mm

• Filtration Rating: 40 microns

• Structure: Depth filter with uniform pore distribution

• Reusable: Supports multiple cleanings without degradation

• Corrosion Resistance: Suitable for aggressive gases & liquids

• Applications: Inline filtration, venting, pressure protection

• Industries: Pneumatics, instrumentation, automotive, chemicals

Common Applications:

• Pneumatic control system filters

• Instrumentation line protection

• Fuel or solvent filtration

• Inline or embedded air filtration units

• Vent protection for tanks or enclosures

• Breather elements for pressure-sensitive devices

FAQ – Frequently Asked Questions

Q1: What particles does a 40-micron stainless filter block?
It captures particles ≥40µm, making it ideal for fine particle control in industrial systems.

Q2: Can this filter cap be cleaned and reused?
Yes. It is engineered for multiple reuse cycles through ultrasonic or backflush cleaning.

Q3: Is this filter compatible with aggressive chemicals?
Yes. Its stainless steel construction resists corrosion and thermal breakdown.

Q4: How does this differ from mesh or plastic filters?
Sintered stainless filters offer deeper filtration, higher strength, and longer life.

Q5: Can DALON produce this filter in custom sizes?
Absolutely. Custom dimensions, shapes, and micron ratings are available on request.
