Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | 3.9 |
| O.D. (D1) | |
| Length (L) | 17 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The STEEL FILTER CONE 3.9×17 80MICRON is a sintered air filter element in compact conical form, engineered for high-efficiency particle filtration in air or gas applications. Manufactured from stainless steel powder via sintering, this cone delivers uniform porosity and stable flow characteristics, with a nominal pore size of 80 microns.
With a base diameter of 3.9 mm and an overall length of 17 mm, the conical geometry provides expanded surface area and optimal flow dynamics in tight installations. It is ideal for venting, pneumatic systems, gas outlets, and protection of sensitive devices like pressure sensors or flow regulators.
The stainless steel construction ensures excellent resistance to corrosion, oxidation, and temperature cycling. This cone filter supports multiple cleaning cycles, making it a cost-effective and sustainable solution for high-purity gas filtration.
| Specification | Value |
|---|---|
| Material | Stainless Steel (Sintered) |
| Base Diameter | 3.9 mm |
| Length | 17 mm |
| Shape | Conical |
| Filtration Rating | 80 micron (nominal) |
| Porosity Type | Depth filtration |
| Media Cleanability | Reusable, backflush-safe |
| Temperature Range | –200°C to +600°C |
| Pressure Resistance | Suitable for compressed gas lines |
Air vent filters for sealed chambers
Pneumatic control system filtration
Instrument air protection (sensors & gauges)
Exhaust outlets for gas measurement devices
Compact filtration in laboratory setups
Air line filtration in dosing or mixing systems
Filter tips for portable gas monitoring units
Q1: What is the main purpose of this sintered air filter cone?
It filters dust and particles from compressed air or dry gas before they reach sensitive equipment.
Q2: Can the cone be used in high-pressure gas systems?
Yes. The stainless steel body handles moderate compressed gas pressures with stability and reliability.
Q3: Is the filter cone reusable?
Absolutely. It can be cleaned by backflushing, ultrasonic baths, or chemical soaking depending on the contamination.
Q4: Does the cone shape improve filtration?
Yes. The conical geometry increases surface area and promotes smoother airflow, especially in directional flow applications.
Q5: Can DALON supply custom dimensions or different micron sizes?
Yes. We offer custom manufacturing options including pore size, cone dimensions, and attachment types.
The versatility of STEEL FILTER CONE 3.9X17 80MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
Our professional team is ready to assist with your inquiry for this Cone Filter for Air Venting & Emission Lines – 80µm.
Contact UsAll our products are manufactured according to ISO 9001 standards.
View CertificatesWe offer free design services and custom manufacturing for your specific needs.
We provide worldwide shipping for all our products with reliable delivery times.
