Premium Quality Sintered Steel Filter
| I.D.(d) | 16.2 |
| I.D. (d1) | |
| O.D. (D) | 99 |
| O.D. (D1) | |
| Length (L) | 4 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The STEEL FILTER DISC 16.2×99×4 40MICRON is a sintered metal filter element engineered for precise filtration in compact, inline, or directional flow applications. Made from stainless steel powder through high-temperature sintering, the disc delivers uniform 40-micron pore structure, excellent mechanical strength, and stable flow performance.
Its elongated profile—16.2 mm in width, 99 mm in length, and 4 mm in thickness—makes it ideal for installation in slots, channels, and OEM filter compartments where laminar flow or large surface contact is needed. The porous metal matrix performs depth filtration, trapping contaminants throughout its thickness for higher dirt-holding capacity.
The stainless steel construction ensures superior resistance to corrosion, pressure, vibration, and thermal cycling. The filter disc is fully cleanable and reusable, reducing maintenance frequency and system downtime.
| Specification | Value |
|---|---|
| Material | Stainless Steel (Sintered) |
| Width (Short Side) | 16.2 mm |
| Length (Long Side) | 99 mm |
| Thickness | 4 mm |
| Filtration Rating | 40 micron (nominal) |
| Porosity Type | Depth filtration |
| Media Cleanability | Reusable, ultrasonic-safe |
| Temperature Range | –200°C to +600°C |
| Pressure Resistance | Suitable for compressed gas/liquid |
Laminar flow filtration for clean gas systems
Compressed air and inert gas purification
Inline filters for pneumatic regulators
Sampling line filtration for lab instruments
Process filtration in fluid dosing equipment
Dust and particle filtration for actuators
Analyzer and sensor inlet protection
Q1: What makes this sintered metal filter ideal for inline applications?
Its elongated shape, durable structure, and 40µm pore size make it perfect for directional flow control in compact systems.
Q2: Can the disc be cleaned and reused?
Yes. The stainless steel material is fully reusable and supports ultrasonic cleaning, backflushing, and chemical rinsing.
Q3: What’s the difference between depth filtration and surface filtration?
Depth filtration traps particles within the filter body, increasing dirt capacity and preventing surface clogging.
Q4: Is this disc compatible with reactive gases or fluids?
Yes. The stainless steel construction is chemically stable across a wide range of industrial gases and liquids.
Q5: Can I request custom sizes or different micron ratings?
Yes. DALON offers complete customization including pore size, dimensions, thickness, and fitting options.
The versatility of STEEL FILTER DISC 16.2X99X4 40MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
