STEEL FILTER DISC 90X2 100MICRON

DALON’s STEEL FILTER DISC 90×2 100MICRON is a premium sintered metal filter engineered for demanding industrial filtration applications. With a pore size of 100 microns, this stainless steel disc is ideal for coarse particle filtration, flow control, and media protection in gas, air, and liquid systems.

The disc is 90 mm in diameter and 2 mm in thickness, offering a broad filtration surface while maintaining a compact profile for easy integration. Manufactured using DALON’s advanced powder metallurgy sintering process, the filter body is fused into a rigid, durable structure with uniform porosity, excellent strength, and chemical resistance.

This filter disc is commonly used in systems requiring high throughput, thermal stability, and long service life under varying pressure or temperature. It is reusable, cleanable, and resistant to corrosion, making it a cost-effective solution over repeated cycles.

Key Features:

• Material: Stainless Steel (typically SS316L)

• Size: 90 mm diameter × 2 mm thickness

• Pore Size: 100 microns

• Filtration Type: Depth filtration via sintered porous metal

• Mechanical Strength: Rigid and crack-resistant design

• Reusable: Supports ultrasonic or backflush cleaning

• Compatibility: Works with gas, water, solvents, and mild chemicals

• Typical Use Cases: Gas filtration, process fluid protection, pneumatic system filters, pressure regulators, and flame arresters

Benefits of DALON’s Sintered Metal Filters:

• Uniform filtration and stable flow rate

• No shedding or media migration

• High operating temperature and pressure tolerance

• Custom shapes and sizes available on request

• Complies with international filtration standards

FAQ – Frequently Asked Questions

Q1: What is the function of a 100-micron sintered metal filter?
It removes larger particles from gases or liquids, commonly used as a pre-filter or protective layer in filtration systems.

Q2: Can this filter disc be cleaned and reused?
Yes. It can be cleaned using ultrasonic baths, backflushing, or chemical soaking depending on the contaminant.

Q3: What industries use this type of sintered filter disc?
Applications include air dryers, chemical processing, fuel systems, instrumentation, and pneumatic or hydraulic assemblies.

Q4: Why choose sintered stainless steel over mesh or fiber filters?
Sintered steel offers superior durability, thermal/chemical resistance, and a precise, non-deforming pore structure.

Q5: Is the 90mm disc customizable?
Yes. DALON can tailor pore size, material type, and dimensions to meet your application needs.
