STEEL FILTER TUBE 12X16X14 50MICRON

Sintered Metal Filter – Steel Filter Tube 12×16×14 mm, 50 Micron

DALON’s 12×16×14 mm sintered metal filter tube offers precise and durable 50-micron filtration for use in compressed gas, hydraulic, fuel, and process fluid systems. Manufactured from sintered stainless steel or alloy steel, the porous filter body delivers high strength, uniform pore distribution, and resistance to heat and corrosion.

This compact cylindrical filter is ideal for OEM integration into sensor protection, valve assemblies, flow restrictors, or as a pre-filter for critical filtration stages. The sintering process ensures consistent porosity and long-lasting filtration under high-pressure or high-temperature conditions.

Key Specifications

• Material: Sintered stainless steel or alloy steel

• Outer Diameter (OD): 16 mm

• Inner Diameter (ID): 12 mm

• Length: 14 mm

• Micron Rating: 50 µm

• Porosity Type: Controlled, fixed pore structure

• Operating Temp: Up to 500°C

• Operating Pressure: Up to 25 bar (varies by housing)

Key Features

• Stable Pore Structure: Uniform 50µm rating for repeatable filtration

• Corrosion Resistant: Withstands aggressive gases, fluids, and chemicals

• Thermally Stable: Ideal for high-temperature applications

• Cleanable & Reusable: Can be cleaned via ultrasonic, solvent, or backflush

• Compact & Robust: Supports press-fit or threaded housing integration

Applications

• Air and gas filtration in pneumatic systems

• Fuel injectors and burner filters

• Hydraulic and lubrication systems

• Flow control devices and restrictors

• Sensor and transducer protection

• Chemical dosing and vent filtration

• Food, pharmaceutical, and ink systems

Why Choose DALON

As an ISO 9001:2015-certified manufacturer, DALON offers over 20 years of expertise in sintered metal filtration solutions. Our filters are trusted by global OEMs for performance in harsh, regulated, or precision-critical environments.

We offer:

• Custom diameters, lengths, and micron ratings

• Multiple metal options (316L, 304, Inconel, Hastelloy)

• OEM design integration for custom filter shapes

• Optional end caps, flanges, and sealing features

• High-volume production with short lead times

FAQ – Frequently Asked Questions

Q1: What is a sintered metal filter?
It is a porous metal element formed by compressing and heating metal powders to create a rigid, uniform filter structure.

Q2: Can I clean and reuse this filter?
Yes. These filters are fully reusable and can be cleaned using ultrasonic baths, solvents, or backflushing.

Q3: What kind of media does it filter?
Gas, air, water, oil, fuel, chemicals, or steam depending on system compatibility.

Q4: Is this compatible with aggressive fluids or high temperatures?
Yes. Stainless steel sintered filters can withstand high chemical exposure and up to 500°C operating temperature.

Q5: Can I request a different micron rating or shape?
Absolutely. DALON supports full OEM customization including micron grade, shape, and connector design.

Q6: What makes it better than mesh or paper filters?
Sintered filters are stronger, non-shedding, reusable, and better for precise and critical filtration applications.
