STEEL FILTER ELEMENTS 40X47X5 100MICRON

Premium Quality Sintered Steel Filter

DALON SPECIAL DESIGN

Product Overview

Product Specifications

Manufacturer DALON
Material POROUS STAINLESS STEEL
Type SPECIAL DESIGN
Reference Drawing
Product Code DLP202109209
Pore Pitch 100MICRON
HS Code 84219990
RoHS Compliant
REACH Compliant

Technical Drawings & Dimensions

sintered metal mesh Technical Drawing

Product Dimensions

I.D.(d)
I.D. (d1)
O.D. (D)
O.D. (D1)
Length (L)
Flange Dia. (fd)
Flange Thickness (fl)
General Tolerance ±0.3mm
Weight(ref)/Gram 0.00
Minimum Order Qty 0
All dimensions in millimeters (mm) unless otherwise specified.

Product Description

Sintered Mesh Filter Element – For Industrial Flow Control

STEEL FILTER ELEMENTS 40X47X5 100MICRON Additional image 1

DALON’s sintered metal mesh filter element, sized at 40 mm × 47 mm × 5 mm, with a 100-micron nominal rating, is engineered for coarse filtration where strength, reusability, and high flow rates are essential. Manufactured from sintered stainless steel wire mesh, this element features a rigid porous structure capable of withstanding elevated temperatures, chemical exposure, and mechanical stress.

The 100µm mesh construction is ideal for removing larger particulates like rust flakes, weld slag, and processing residue from air, fuel, water, or hydraulic systems. Its metallic durability ensures it will not degrade over time, unlike polymer or fiber-based filters.

DALON’s sintered mesh filters are commonly used in gas sampling, hydraulic pressure systems, vacuum pump protection, air compressors, and industrial cooling loops, particularly where filter elements need to be washed and reused repeatedly without performance loss.


Key Features

  • Filtration Rating: 100 microns (nominal)

  • Size: 40 mm outer diameter × 47 mm length × 5 mm wall thickness

  • Material: Sintered stainless steel wire mesh (typically SS316L or SS304)

  • High strength & corrosion resistance

  • Reusable and cleanable design

  • Withstands high-pressure and high-temperature conditions

  • Stable pore structure for consistent flow rates


Applications

  • Filtration of coolants, lubricants, and hydraulic oil

  • Pre-filtration for fuel and air intake systems

  • Protective screens for compressors and regulators

  • Inline filters in chemical process systems

  • Venting and filtering in battery systems or motor housing

  • Washable filter component in cleaning or recycling equipment


Why Choose DALON

DALON is an ISO 9001:2015-certified OEM supplier specializing in precision-engineered sintered filter solutions for global industrial and commercial markets. Our sintered mesh filter elements offer excellent reliability, dimensional accuracy, and performance consistency.

Advantages include:

  • Custom micron ratings from 5–200 µm

  • Configurable dimensions, threads, and housing fittings

  • Lead time: Standard stock delivered in ~30 days; custom tooling in 35–40 days

  • Engineering support for integration in OEM designs

  • Prototypes and batch production available

Whether you need durability, precision, or cost-efficiency, DALON delivers high-quality filtration solutions tailored to your requirements.


FAQ – Frequently Asked Questions

Q1: What contaminants does a 100µm sintered metal mesh filter remove?
It captures coarse particles like metal debris, machining residue, and particulate buildup from fluids or gases.

Q2: Is this filter reusable?
Yes. The steel mesh can be cleaned with air, water, or ultrasonic systems for multiple reuse cycles.

Q3: What is the typical operating temperature limit?
Sintered steel filters can withstand temperatures up to 500°C, depending on grade and application.

Q4: Can this filter be used in food or pharma applications?
It depends on your process. Stainless steel is food-safe, but please confirm material compliance with your industry standards.

Q5: How do I know what micron size I need?
Micron rating selection depends on your system’s sensitivity and the size of particles you want to remove. Contact DALON for guidance.

Q6: What is the minimum order quantity for custom filters?
MOQ varies depending on size and complexity. Please contact DALON for custom inquiries and volume discounts.


People Also Ask – Answered

What is sintered metal mesh?
It’s a porous structure formed by bonding layers of wire mesh through sintering, offering durable, cleanable filtration for industrial uses.

Is sintered mesh better than woven mesh?
Yes. Sintered mesh is more rigid and stable, providing better mechanical strength and consistency across cycles.

Can sintered metal mesh filters handle high flow rates?
Yes. Their open structure and strength make them ideal for high-throughput systems with moderate filtration requirements.

Additional image 2
STEEL FILTER ELEMENT 40×47×5 mm – sintered metal mesh filter with 100µm rating for coarse gas, oil, and liquid filtration in rugged industrial systems.

Applications & Industries

Filter Silencing Applications Filter Silencing Applications

Chemical & Manufacturing

  • CHEMICAL INDUSTRIES
  • SEMICONDUCTOR
  • SCIENTIFIC INSTRUMENT
  • PHARMACEUTICAL
  • POLYMER FILTRATION
  • GAS AND LIQUID FILTRATION
Fluidization Applications Filter Silencing Applications

Common Applications

  • SILENCING
  • SPARGING
  • FLUIDIZATION
  • SENSOR AND VALVE PROTECTION
  • FLOW RESTRICTION
  • HANDLING OF BULK MATERIAL
Filter Applications

Industry Solutions

The versatility of STEEL FILTER ELEMENTS 40X47X5 100MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:

Chemical & Pharmaceutical:
- For precise filtration in chemical processing, pharmaceutical manufacturing, and laboratory applications.
Semiconductor & Electronics:
- In clean room environments and semiconductor manufacturing where high-purity filtration is critical.
Manufacturing & Processing:
- For industrial gas and liquid filtration in manufacturing processes and production lines.
Water & Waste Treatment:
- In water purification systems and wastewater treatment where reliable filtration is essential.
Air & Gas Systems:
- For air filtration, gas distribution, and pneumatic systems requiring precise flow control.
