STEEL FILTER DISC 20X2 50MICRON

The STEEL FILTER DISC 20×2 50MICRON from DALON is a sintered powder filter disc engineered for precision filtration in compact and space-limited environments. Manufactured using high-quality stainless steel powder and advanced sintering techniques, this 20 mm diameter and 2 mm thick disc ensures consistent 50-micron particle retention in applications involving air, gas, light oils, or industrial fluids.

Its porous metal structure provides reliable depth filtration, excellent mechanical strength, and resistance to corrosion, pressure, and temperature, making it suitable for long-term industrial use.

The sintered design not only offers stability and flow consistency but is also fully cleanable and reusable, reducing replacement costs and minimizing downtime.

Key Features:

• Material: Sintered stainless steel (typically SS316L)

• Size: 20 mm diameter × 2 mm thickness

• Pore Size: 50 microns

• Filtration Type: Depth filtration with uniform pore structure

• Durability: Withstands high pressure and temperature environments

• Chemical Compatibility: Safe for gases, oils, solvents, and water

• Reusability: Washable with ultrasonic cleaning, solvents, or air backflush

• Customization: Other sizes and pore ratings available upon request

Common Applications:

• Pneumatic and hydraulic systems

• Instrumentation ports and sensor protection

• Medical and laboratory gas handling

• Fuel or lubrication systems

• Flame arresters and pressure regulators

• Compressed air dryers and filtration panels

FAQ – Frequently Asked Questions

Q1: What does 50-micron rating mean in filtration?
It filters out particles larger than 50 microns, suitable for pre-filtration or coarse particle control.

Q2: Can this filter disc be reused after cleaning?
Yes, sintered powder filters are designed for multiple cleaning cycles without structural degradation.

Q3: Is 2 mm thickness enough for high pressure?
Yes, for its compact size, the sintered structure is strong enough for most standard air or fluid systems. For high-pressure use, consult DALON for reinforced options.

Q4: Can this disc be welded or press-fitted into housings?
Yes, depending on the design. It supports press-fit, bonding, and welding.

Q5: Is there a risk of media shedding?
No. The sintered metal design ensures stable pore structure with no fiber shedding or particle migration.
