STEEL FILTER DISC 6.35X1.6 40MICRON

DALON’s STEEL FILTER DISC 6.35×1.6 40MICRON is a compact and efficient sintered powder filter designed for medium-precision gas and liquid filtration. Built from stainless steel powder through high-temperature sintering, this filter disc provides a 40-micron filtration rating, ideal for capturing moderate-sized particles in systems requiring stable flow and compact integration.

With a diameter of 6.35 mm and thickness of 1.6 mm, this miniature disc filter is particularly well-suited for sensor ports, valve seats, fuel lines, and air flow controllers, where space is limited but filtration performance is critical.

DALON’s sintered discs feature a uniform porous structure that maintains mechanical integrity under pressure, temperature variation, and corrosive environments. The disc is reusable and supports various cleaning methods including ultrasonic and chemical soaking, ensuring cost-effectiveness and durability.

Key Features:

• Material: Stainless Steel (typically SS316L)

• Size: 6.35 mm diameter × 1.6 mm thickness

• Micron Rating: 40 microns

• Construction: Sintered powder metal

• Flow Control: Stable flow with low resistance

• Chemical Resistance: Ideal for solvents and corrosive fluids

• Reusable: Easy to clean and reinstall

• Application Fit: Perfect for miniature assemblies and protective filtration

Typical Applications:

• Instrumentation and control devices

• Small pneumatic systems

• Fuel and oil flow protection

• Medical gas sampling systems

• Air or vapor filtration

• Sensor protection caps

FAQ – Frequently Asked Questions

Q1: What does “40 micron” mean for this filter disc?
It means the filter can trap particles down to 40 microns in diameter while maintaining high flow and low pressure drop.

Q2: Is this filter reusable?
Yes, it is designed for repeated use and supports cleaning with ultrasonic or solvent-based methods.

Q3: What’s the benefit of using sintered powder metal?
Sintered metal provides uniform pores, high mechanical strength, and long-term resistance to heat and corrosion.

Q4: Where is this type of filter typically used?
It’s often used in small flow systems such as sensors, valves, air control devices, and micro fuel channels.

Q5: Can this disc be customized?
Absolutely. DALON offers custom sizes, thicknesses, and micron ratings to fit your specific application needs.
