STEEL FILTER TUBE 24X30.1X37.4 5MICRON

DALON’s STEEL FILTER TUBE 24×30.1×37.4 5MICRON is a high-performance sintered stainless steel powder filter tube designed for fine filtration applications across a wide range of air, gas, and liquid systems. Manufactured using 316L stainless steel powder metallurgy, the filter delivers precise 5-micron filtration, high mechanical strength, and excellent resistance to corrosion, pressure, and temperature.

With an inner diameter of 24 mm, outer diameter of 30.1 mm, and length of 37.4 mm, this compact tubular filter integrates easily into housings and manifolds in instrumentation, pneumatics, fuel lines, and process control systems. Its depth filtration structure ensures stable flow and minimal clogging.

The filter’s sintered porous body is fully reusable, supporting multiple cleaning cycles via ultrasonic washing, backflushing, or solvent rinsing, helping reduce operational costs while maintaining high filtration efficiency.

Key Features:

• Material: Sintered Stainless Steel 316L

• Size: 24 mm ID × 30.1 mm OD × 37.4 mm length

• Filtration Rating: 5 microns

• Structure: Porous sintered tube for depth filtration

• Reusability: Ultrasonic/solvent/backflush cleanable

• Performance: High pressure and thermal resistance

• Compatibility: Air, gas, oil, fuel, water, solvents, and chemicals

• Installation: Compact fit for OEM systems and industrial assemblies

Common Applications:

• Fuel injection and fuel cell systems

• Air and gas drying systems

• Pressure regulator and valve protection

• Instrumentation panels and analyzers

• Pneumatic and hydraulic circuit filters

• Chemical dosing and sampling filters

FAQ – Frequently Asked Questions

Q1: What is the filtration capability of 5 microns?
It traps particles ≥5µm, suitable for fine filtration in sensitive air, gas, or liquid systems.

Q2: Can this filter tube be reused?
Yes. It is designed for repeated cleaning with backflush, ultrasonic, or solvent methods.

Q3: Why choose a sintered powder filter over mesh?
Sintered powder filters offer consistent pore control, depth filtration, and longer lifespan without deformation.

Q4: Will it resist corrosion from chemicals or solvents?
Yes. The 316L stainless steel body is corrosion-resistant and suitable for harsh media.

Q5: Is customization available?
Absolutely. DALON provides custom sizing, pore ratings, and material combinations on request.
