STEEL FILTER TUBE 12.65X17X57 50MICRON

DALON’s STEEL FILTER TUBE 12.65×17×57 50MICRON is a high-performance stainless steel air filter designed for 50-micron gas and air filtration in industrial and pneumatic systems. Manufactured using sintered 316L stainless steel, this filter tube offers depth filtration, mechanical durability, and stable airflow under high-pressure conditions.

With an inner diameter of 12.65 mm, outer diameter of 17 mm, and length of 57 mm, this filter tube provides a compact and robust solution for inline filtration in air compressors, pneumatic valves, control panels, or vacuum systems. Its 50µm rating effectively traps medium-size airborne particles while maintaining a low pressure drop.

The sintered structure ensures consistent pore distribution, corrosion resistance, and thermal stability. The filter is fully cleanable and reusable, supporting backflushing, ultrasonic cleaning, or solvent soaking, making it a cost-effective long-term solution.

Key Features:

• Material: Sintered Stainless Steel 316L

• Size: 12.65 mm ID × 17 mm OD × 57 mm length

• Filtration Rating: 50 microns

• Structure: Cylindrical porous tube for air/gas depth filtration

• Durability: High-pressure and temperature-resistant

• Reusability: Washable with ultrasonic, solvent, or reverse airflow

• Flow Performance: Low resistance, stable air throughput

• Applications: Pneumatics, air drying, exhaust, sensor protection

Common Applications:

• Air compressor outlet and intake filtration

• Pneumatic tool and actuator protection

• Air-drying or vacuum systems

• Venting in process equipment and control boxes

• Gas or vapor filtration in chemical and lab settings

• Pressure regulator and solenoid valve inlet filters

FAQ – Frequently Asked Questions

Q1: What is the function of a 50-micron air filter tube?
It removes airborne particles ≥50µm, preventing contamination in pneumatic or gas systems.

Q2: Is this filter tube reusable?
Yes. It supports multiple cleaning cycles with ultrasonic, backflush, or solvent methods.

Q3: How does sintered stainless perform under pressure?
The 316L material maintains strength and pore structure even in high-pressure or corrosive environments.

Q4: Why choose a tubular filter design?
Tubular designs offer more surface area and internal flow volume, allowing higher throughput with compact size.

Q5: Can DALON provide customized versions?
Absolutely. Size, material, and pore rating can be customized for your specific air filtration application.
