Premium Quality Sintered Steel Filter
| I.D.(d) | |
| I.D. (d1) | |
| O.D. (D) | |
| O.D. (D1) | |
| Length (L) | |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | ±0.2mm |
| Weight(ref)/Gram | 0.00 |
| Minimum Order Qty |
The SINTERED STAINLESS STEEL FILTER 50MICRON is a high-performance breather filter element designed to protect enclosed systems from particle contamination while allowing pressure equalization. Manufactured from stainless steel powder through sintering, it offers robust filtration and air permeability in a compact form.
With a nominal pore size of 50 microns, this breather filter is ideal for preventing dust, dirt, and debris from entering sensitive systems like hydraulic tanks, gearboxes, pneumatic housings, or electronic enclosures. Its depth filtration structure ensures high dirt-holding capacity while allowing unrestricted air movement.
The corrosion-resistant stainless steel body ensures long-term performance even in chemically aggressive or humid environments. Unlike disposable filters, this unit is fully reusable and supports cleaning via backflushing or ultrasonic methods. It is suitable for threaded, flanged, or press-fit breather ports.
| Specification | Value |
|---|---|
| Material | Sintered Stainless Steel (304/316L) |
| Filtration Rating | 50 micron (nominal) |
| Filter Type | Breather / Ventilation Filter |
| Porosity Type | Depth filtration |
| Media Cleanability | Reusable, backflush/ultrasonic |
| Temperature Range | –200°C to +600°C |
| Pressure Resistance | Suitable for vented and sealed systems |
Hydraulic reservoir breather vents
Gearbox air pressure equalization
Storage tank or drum air vents
Pneumatic enclosure ventilation
Chemical tank breather filters
Dust prevention for electronic housings
Environmental equipment vent protection
Q1: What is a breather filter used for?
It allows air to move in and out of a sealed system while filtering out contaminants like dust and particles.
Q2: Is 50µm filtration fine enough for industrial use?
Yes. 50 microns is optimal for general-purpose breathing/venting applications where airflow and particle protection must be balanced.
Q3: Can this filter be used in corrosive or humid environments?
Yes. The stainless steel structure resists corrosion and is ideal for outdoor or chemically exposed applications.
Q4: Is this breather filter reusable?
Absolutely. It can be cleaned and reused multiple times without loss of filtration performance.
Q5: Can DALON customize this breather filter for size or connection type?
Yes. We offer threaded, flanged, welded, or custom-designed sintered breather filters upon request.
The versatility of SINTERED STAINLESS STEEL FILTER 50MICRON makes them ideal for various industrial applications. Key industries that benefit from these steel filters include:
