STEEL FILTER TUBE 52.1X57.1X14.2 30MICRON

DALON’s STEEL FILTER TUBE 52.1×57.1×14.2 30MICRON is a robust, compact stainless steel gas filter designed for medium-level gas filtration in compressed air, fuel vapor, and high-pressure gas handling systems. Constructed from sintered 316L stainless steel powder, this filter delivers 30-micron precision, uniform flow, and high mechanical strength.

With an inner diameter of 52.1 mm, outer diameter of 57.1 mm, and a length of 14.2 mm, this sintered tube offers low-pressure drop and reliable depth filtration for use in manifolds, gas dryers, valves, or protective housings. The filter is built for reusability, compatible with ultrasonic cleaning, solvent rinsing, or backflushing to reduce downtime and operational cost.

The porous metal structure is ideal for applications requiring stable flow, corrosion resistance, and thermal durability, even under fluctuating pressure or gas composition.

Key Features:

• Material: Sintered Stainless Steel 316L

• Size: 52.1 mm ID × 57.1 mm OD × 14.2 mm length

• Filtration Rating: 30 microns

• Design: Tube-type structure for inline or housing installation

• Reusability: Supports cleaning and multiple-use cycles

• Performance: Excellent gas flow, stable pore structure

• Applications: Fuel vapor, air compression, gas sampling, pneumatic valves

• Resistance: Corrosion, vibration, high pressure and heat

Common Applications:

• Gas compressor and pressure regulator filtration

• Fuel vapor vent systems

• Pneumatic air dryers and filtration units

• Control valve and manifold protection

• Sensor ports in analytical or chemical devices

• Gas flow restrictors or particle scrubbers

FAQ – Frequently Asked Questions

Q1: What particles does this 30µm gas filter remove?
It effectively captures particles ≥30 microns from compressed gases, vapors, and air.

Q2: Can it be cleaned and reused?
Yes. The sintered stainless steel structure is washable with backflushing, solvent soaking, or ultrasonic cleaning.

Q3: Will this handle high-pressure gas?
Absolutely. The 316L body is mechanically stable under high pressure and cyclic loads.

Q4: Is it suitable for fuel vapor or corrosive gas?
Yes. The filter resists most fuels, vapors, and industrial gases.

Q5: Can DALON customize the size or pore rating?
Yes. We offer OEM customization in size, pore rating, and integration design.
