Bague coulissante de qualité premium
| Fabricant | DALON |
| Matériau | COMPOSITE MULTILAYER |
| Type | FLANGE BUSHING |
| Température de fonctionnement ?/td> | From -200°C to + 280°C |
| Code produit | BMF14162212 |
| Densité (g/cm³) | 7.5 |
| Code HS | 8483300090 |
| Dureté | >220 |
| Charge statique (Mpa) | 250 |
| Vitesse max. (m/s) | 2.5 |
| Max PV (sec) | 1.8 |
| I.D.(d) | 14 |
| I.D. (d1) | |
| A.D. (D) | 16 |
| A.D. (D1) | |
| Länge (L) | 1 |
| Flanschdurchmesser (fd) | 22 |
| Flanschdicke (fl) | 12 |
| Allgemeine Toleranz | F7 r7 js13 |
| Poids(Réf.)/Gramme | 0.00 |
| Quantité minimum de commande | 40KGS |
DALON’s Flanged Sliding Bush Bearing 14×16×22×1×12 is a precision-engineered component designed for compact and high-precision motion systems requiring both axial positioning and low-friction radial support. Constructed from a cold-formed, high-density bronze alloy, this flanged bushing delivers superior durability, quiet operation, and long-lasting performance without the need for continuous lubrication.
The product dimensions follow DALON’s standard format for flanged bushings:
ID: 14 mm
OD: 16 mm
Flange OD: 22 mm
Flange Thickness: 1 mm
Total Length: 12 mm
Its integrated flange ensures positive axial retention during press-fit installation, reducing the need for additional hardware or fastening components. This bushing is particularly well-suited for applications involving moderate loads and speeds, where traditional bearings may suffer from debris intrusion or lubrication failure.
Size: 14 × 16 × 22 × 1 × 12 mm (ID × OD × Flange OD × Flange Thickness × Total Length)
Material: Bronze-based alloy (oilless and corrosion-resistant)
Lubrication: Self-lubricating via diamond-patterned indents or optional embedded graphite
Operating Temp: –40°C to +250°C
Load Capacity: Up to 60 N/mm² (dynamic)
Applications: Dry, dusty, or intermittent lubrication environments
Durability: Excellent wear resistance, long service intervals
Compact actuator assemblies
Electric motor housings and gear drives
Robotics joints and gripper pivots
Medical or laboratory automation devices
Lightweight machinery and 3D motion systems
Pneumatic slides and pick-and-place units
Tailor-made solutions: Custom bushing sizes, materials, and lubricant options
Fast turnaround:
Existing mold sizes ship in ~30 days
Custom designs (incl. tooling) in 35–40 days
Reliable Quality: Manufactured under ISO 9001:2015
Low MOQ for prototyping or pre-series production
Engineering support: Assembly tolerances, PV/load calculations, and fitting analysis
|
Question |
Answer |
|---|---|
|
Q1: What is a bush bearing used for? |
Bush bearings are used to reduce friction and wear in sliding or rotating parts, offering reliable support without rolling elements. |
|
Q2: What does flanged mean in bush bearings? |
A flange provides a built-in stop to prevent axial movement, ideal for easy axial location in housings. |
|
Q3: Can this flanged bushing be used without grease? |
Yes, it is self-lubricating and suitable for dry or marginally lubricated conditions. |
|
Q4: Is this bushing suitable for high-speed applications? |
It supports moderate speeds; for high-speed operations, consult DALON for suitable PV limits. |
|
Q5: What is the delivery time for custom bushings? |
Around 35–40 days including mold design; standard sizes can ship in 30 days or less. |
|
Q6: What industries use sliding flange bushings? |
Common in automation, robotics, medical equipment, packaging machinery, and precision tools. |
Les propriétés auto-lubrifiantes des SLIDING FLANGE BUSHING 14X16X22X1X12 les rendent idéales pour de nombreuses applications, notamment :
SLIDING FLANGE BUSHING 14X16X22X1X12 sont conçues pour des environnements où la lubrification conventionnelle est impraticable ou impossible. Elles offrent des performances exceptionnelles, une durabilité et des économies de coûts, faisant d'elles le choix privilégié dans diverses industries. Découvrez la fiabilité et l'efficacité des SLIDING FLANGE BUSHING 14X16X22X1X12, adaptées pour répondre aux exigences de vos applications spécifiques.
Notre équipe professionnelle est prête à vous aider avec votre demande pour cette Flanged Bush Bearing 14×16×22×1×12 – Oilless Bronze for Low Friction.
