Premium Quality Sintered Bushing
| I.D.(d) | 20 |
| I.D. (d1) | |
| O.D. (D) | 28 |
| O.D. (D1) | |
| Length (L) | 20 |
| Flange Dia. (fd) | |
| Flange Thickness (fl) | |
| General Tolerance | F7 r7 js13 |
| Weight(ref)/Gram | 40.00 |
| Minimum Order Qty | 40KGS |
DALON’s 20×28×20 mm brass sleeve bushing is a high-performance sintered bronze bearing designed for industrial and mechanical applications requiring silent operation, high durability, and self-lubrication. Produced using powder metallurgy, the bushing features an interconnected porous structure that retains lubricating oil, enabling extended dry operation without additional maintenance.
This sleeve-type configuration is ideal for rotary motion systems, especially where regular greasing is impractical or impossible. Its 20 mm inner diameter and robust bronze composition make it suitable for medium-duty shafts and housing assemblies.
Dimensions: 20 mm ID × 28 mm OD × 20 mm Length
Material: Sintered bronze (typically Cu90/Sn10 alloy)
Type: Sleeve bushing, cylindrical shape
Self-lubricating – no external lubrication needed
Uniform porosity for consistent oil dispersion
Quiet, vibration-damping operation
Excellent load distribution and wear resistance
Electric motors and fan units
Agricultural and forestry equipment
Industrial automation shafts
Power tools and drive systems
HVAC actuators and compressors
Office machines, textile devices, and conveyors
DALON is an ISO 9001:2015-certified global manufacturer of precision sintered bronze bushings. Our brass sleeve bushings are trusted by OEMs worldwide for their stability, efficiency, and long life in demanding applications. Every product is precision-formed and quality-checked to meet high mechanical and dimensional tolerances.
We support full OEM customization in shaft size, bushing tolerances (H7/H9), material formulation, or mounting style (flanged, washer-included, special groove options). Our engineers are available to optimize bushing selection for your exact mechanical system.
Q1: What is the difference between a sleeve bushing and a flange bushing?
A sleeve bushing is cylindrical and fits flush within a housing, while a flange bushing includes a collar for axial positioning or load-bearing.
Q2: Does this bushing require oil or grease?
No. It is self-lubricating. Oil is impregnated in the sintered bronze during manufacturing, allowing maintenance-free use.
Q3: Can this size handle heavy radial loads?
Yes. The 20×28×20 size is designed for moderate to high radial loads in industrial settings.
Q4: Is this bushing suitable for oscillating motion?
Yes. It is ideal for both rotary and oscillating movements due to its low-friction surface and load capacity.
Q5: Can I order this bushing with tighter tolerances?
Yes. DALON provides tailored machining or sizing upon request, including precision ID grinding or reaming.
Q6: What industries use brass sleeve bushings?
These are widely used in automotive, power tools, agricultural machinery, HVAC, packaging equipment, and mechanical design applications.
The versatility of SINTERED BRONZE BUSHING 20X28X20 makes them ideal for numerous applications, including:
SINTERED BRONZE BUSHING 20X28X20 are engineered for demanding applications where traditional lubrication methods are impractical. They provide exceptional performance, durability, and cost-effectiveness, making them the preferred choice across various industries. Experience the reliability and efficiency of SINTERED BRONZE BUSHING 20X28X20, designed to meet your specific application requirements.
Our professional team is ready to assist with your inquiry for this Sintered Bronze Sleeve Bushing – For Pumps, Motors & Tools.
