STEEL FILTER CARTRIDGE 50X179X3 150MICRON

DALON’s 50×179×3 sintered filter cartridge is a high-capacity stainless steel filtration element designed for use in demanding air, gas, or liquid systems. With a 150-micron nominal filtration rating, this cartridge allows efficient throughput while reliably capturing coarse contaminants such as particles, slag, flakes, or scale.

The filter is constructed using sintered stainless steel, offering excellent mechanical strength, corrosion resistance, and temperature stability. Its robust cylindrical shape (50 mm diameter × 179 mm length × 3 mm wall thickness) makes it suitable for inline or housing-mounted filtration units, especially in environments requiring high flow rates with low pressure drop.

The sintered metal matrix features uniform pore distribution, which ensures consistent performance across the entire filter surface. Thanks to its washable and reusable design, this filter significantly reduces operational cost over disposable filters.

Key Specifications

• Filtration Rating: 150 microns (nominal)

• Size: Diameter 50 mm × Length 179 mm × Wall thickness 3 mm

• Material: Sintered stainless steel (SS304 or SS316L optional)

• Flow Capacity: High, suited for large volume fluid/gas transfer

• Operating Temperature: Up to 500°C

• Chemical Compatibility: Resistant to acids, alkalis, solvents

• Reusability: Washable with air, water, solvent, or ultrasonic methods

Applications

• Pre-filtration in chemical and pharmaceutical lines

• Filtration for compressed air and gas delivery systems

• Particle removal in hydraulic fluid circuits

• Fuel and oil filtration in industrial engines

• Water filtration in high-volume processing units

• Dust and debris protection in high-pressure process lines

Why Choose DALON

DALON is a trusted manufacturer of precision sintered metal filter cartridges, serving industrial clients worldwide. We manufacture all filters under ISO 9001:2015, ensuring pore consistency, structural reliability, and material purity.

• Customization Options: Micron rating, length, wall thickness, or connection type

• Fast Turnaround: Standard items ship in 30 days; custom items with mold in 35–40 days

• OEM Support: Engineering drawings, flow testing data, and third-party certifications

• Durable & Sustainable: Reusable design helps reduce cost and waste

FAQ – Frequently Asked Questions

Q1: What does a 150-micron sintered filter cartridge remove?
It filters out coarse debris like rust, scale, chips, and particulates from air or fluid streams without restricting flow.

Q2: Can this cartridge be cleaned and reused?
Yes. The sintered metal structure allows for multiple cleaning cycles using air, water, or ultrasonic cleaning.

Q3: Is this filter cartridge suitable for high flow rates?
Yes. With a 150µm pore size and a large surface area, it's ideal for systems demanding high throughput with minimal resistance.

Q4: Can I use this in a high-temperature system?
Absolutely. The stainless steel body handles temperatures up to 500°C, suitable for thermal and process applications.

Q5: Does DALON offer custom filter cartridge designs?
Yes. We support custom dimensions, pore sizes (5µm to 200µm), connections, and surface finishes—contact us to discuss requirements.

Q6: What industries typically use this type of sintered filter?
Used in petroleum refining, water treatment, air compressor systems, food processing, chemical injection, and automation lines.

People Also Ask – Answered Briefly

What is a sintered filter cartridge used for?
It’s used to trap solid contaminants in liquid or gas pipelines while allowing flow through a durable, porous metal matrix.

How long do sintered metal filters last?
With regular cleaning, they can last for years in non-abrasive environments, making them ideal for long-term industrial use.

Is a 150-micron filter considered fine or coarse?
150µm is considered a coarse filter, mainly used for pre-filtration or bulk debris removal.
