STEEL FILTER TUBE 20X27X80 30MICRON

DALON’s STEEL FILTER TUBE 20×27×80 30MICRON is a high-precision stainless steel filter engineered for 30-micron filtration in air, gas, oil, and chemical applications. Its tubular structure—with a 20 mm inner diameter, 27 mm outer diameter, and 80 mm length—provides increased filtration surface area and flow capacity compared to flat disc filters.

The sintered stainless steel construction ensures a uniform porous structure, enabling depth filtration, low-pressure drop, and mechanical stability under continuous flow or pressurized systems. The 30-micron pore size is ideal for medium particle capture, often used in pre-filtration stages or as a protective filter for downstream equipment.

This filter tube is reusable, chemically resistant, and can withstand thermal stress. It is easily cleaned by ultrasonic washing, backflushing, or solvent rinsing, making it a cost-effective, low-maintenance component for industrial filtration needs.

Key Features:

• Material: Sintered stainless steel (SS316L optional)

• Size: ID 20 mm × OD 27 mm × Length 80 mm

• Filtration Rating: 30 microns

• Design: Tubular, porous depth filter for high flow

• Durability: Heat-, pressure-, and corrosion-resistant

• Reusability: Supports multiple cleaning cycles

• Applications: Compressed air, fuel systems, chemical dosing, hydraulics

• Industries: Automotive, pneumatic, petrochemical, lab analysis

Common Applications:

• Medium filtration in oil & gas transfer systems

• Inline protection for valves and pressure sensors

• Pre-filters in chemical or fuel delivery systems

• Compressed air filtration in pneumatic lines

• Cooling liquid and solvent purification

• OEM filtration modules for high-flow industrial units

FAQ – Frequently Asked Questions

Q1: What can a 30-micron filter tube remove?
It captures particles ≥30µm, typically used for medium to coarse filtration.

Q2: Is this filter washable and reusable?
Yes. You can clean it using backflush, ultrasonic, or solvent-based methods.

Q3: Can it withstand harsh chemicals or heat?
Yes. The stainless steel body resists corrosion, pressure, and high temperatures.

Q4: What are the benefits of a tubular filter design?
The tube offers a larger surface area and more uniform flow than flat discs.

Q5: Can I request custom sizes or micron ratings?
Absolutely. DALON supports OEM customizations for dimension, pore size, and material.
