STEEL FILTER CAP 20X30X40 30MICRON

The STEEL FILTER CAP 20×30×40 30MICRON is a high-performance stainless steel gas filter engineered for critical gas, vapor, and compressed air filtration applications. Made from sintered stainless steel powder (typically SS316L), this filter cap provides uniform 30-micron filtration with strong resistance to corrosion, pressure, and temperature extremes.

With a 20 mm inner diameter, 30 mm outer diameter, and 40 mm total length, it offers a reliable structure for integration into sealed housings or threaded filter assemblies. The sintered design allows for depth filtration, meaning contaminants are trapped not only on the surface but within the 3D porous network — improving dirt-holding capacity and extending service life.

This gas filter cap is ideal for repetitive-use systems, as it can be cleaned and reused multiple times without losing filtration performance.

Key Features

• Material: Sintered stainless steel (SS316L)

• Dimensions: ID 20 mm × OD 30 mm × Length 40 mm

• Filtration Rating: 30 micron nominal

• Design: Rigid sintered matrix for depth filtration

• Flow Performance: High permeability with low pressure drop

• Corrosion Resistance: Handles reactive or moist gases

• Reusability: Washable with solvents or ultrasonic cleaning

• Durability: Pressure and thermal shock resistant

Typical Applications

• Compressed gas purification

• Exhaust vent filters

• Fuel gas and vapor filtration

• Hydrogen or oxygen system filtration

• Industrial gas analyzers

• Pressure regulators & control systems

• Chemical vapor handling

• Vacuum pumps & sensor protection

FAQ – Frequently Asked Questions

Q1: What type of gas media can this filter handle?
This filter is compatible with air, nitrogen, hydrogen, oxygen, natural gas, and various inert or corrosive gases.

Q2: Is this filter reusable?
Yes. It is fully washable using solvents, ultrasonic baths, or backflushing methods.

Q3: How does sintered steel benefit gas filtration?
Sintered steel provides a strong, corrosion-resistant matrix that can filter fine particles while withstanding pressure and temperature changes.

Q4: Is it suitable for high-pressure systems?
Absolutely. The rigid body and SS316L material support high-pressure industrial operations.

Q5: Can I use this in outdoor gas systems?
Yes. The stainless steel construction offers excellent resistance to weather and environmental exposure.
